| Classification |
MINI-PS |
| Rated current |
0.65A |
In
put
|
Phase (φ) |
Single-phase/AC |
| Voltage range |
85 to 264V AC / 90 to 350V DC |
| Frequency |
47 to 63Hz |
| Inrush current |
7A MAX. |
| Power required |
0.2 / 0.4A (230 / 120VAC) |
| Surge protection |
Varistor |
Out
put
|
Rated current |
24V |
| Voltage volatility |
-0% / 3% |
| Holding time |
Less than 400ms |
| Ripple |
20mVpp |
| Operation indication |
LED |
General
Specification
|
Ambient temperature range / Humidity |
-25 to 60°C / -40 to 85°C (Application / Preservation) / 95%(25°C)
Non-condensation |
| Dielectric withstand |
3kV (Input / Output) |
| Standard |
Safe Standard:EN 60950 / VDE 0805,UL1950 / CSA 22.2 NO.950
EMI Standard: CE marking, EMC (89 / 336EWG) |
| Installation |
Direction: Freely / DIN rail attachment (35mm) |
| Connection method |
Screw(M3) Fix type Terminal board |
| Tighten torque |
0.5 to 0.6Nm |
| Connection wire |
AWG: 24 -to 14 / 0.2 to 2.5 mm² |
| Wire exfoliation length |
8 mm |
| Weight |
0.14 kg |
